ejotherm® SDK U

Specification

Applications
- Fastening of rail-systems
- Screw-in anchor for rails
- For fixing holding and base rails
- Approved for all categories of building materials
Properties
- Approved for all categories of building materials
- Shortest embedment depths, minimum drill hole depths
- Highest loads for maximum safety
- Economic anchor usage
- Premounted screw for quick installation
- To compensate facade tolerances use spacers EJOT AS
Technical specifications

Anchor diameter: 8 mm
Collar diameter:16 mm
Drill hole depth h₁ >: 35 mm (75 mm)
Embedment depth h_ef>: 25 mm (65 mm)
Screw drive: TX30
Use categories acc. to ETA: A, B, C, D
German DIBt approval: Z-21.2-1769
European Technical Approval: ETA-04/0023

Values in parentheses: anchoring in aerated concrete (use category E)

Orderidentifier	Article Number	Anchor diameter mm	Length mm	Screw-in-/hammer-inanchor		Unit
ejotherm SDK U 045	8798045400	8.0	45.0	screw-in-anchor	20.0	100
Specifications Anchor diameter 8.0 Length 45.0 Screw-in-/hammer-inanchor screw-in-anchor Embedment depth = 25 20.0 Orderidentifier ejotherm SDK U 045 Unit 100
ejotherm SDK U 065	8798065400	8.0	65.0	screw-in-anchor	40.0	100
Specifications Anchor diameter 8.0 Length 65.0 Screw-in-/hammer-inanchor screw-in-anchor Embedment depth = 25 40.0 Orderidentifier ejotherm SDK U 065 Unit 100
ejotherm SDK U 085	8798085400	8.0	85.0	screw-in-anchor	60.0	100
Specifications Anchor diameter 8.0 Length 85.0 Screw-in-/hammer-inanchor screw-in-anchor Embedment depth = 25 60.0 Orderidentifier ejotherm SDK U 085 Unit 100
ejotherm SDK U 105	8798105400	8.0	105.0	screw-in-anchor	80.0	100
Specifications Anchor diameter 8.0 Length 105.0 Screw-in-/hammer-inanchor screw-in-anchor Embedment depth = 25 80.0 Orderidentifier ejotherm SDK U 105 Unit 100
